- 4寸全频喇叭
- 70铁氧体磁铁 双磁 防磁
- 25芯耐高温音圈 ASV铝骨架
- 高强度的反边铁盆架
- 橡胶悬边哑光纸鼓纸 哑光纸正帽
- 60Hz-4KHz 频响范围
- 85dB灵敏度
- 40W额定功率
- 适用于书架音箱、中置音箱、主音箱
喇叭扬声器
Aa1智泓 AW-425017
| Nominal diameter | 4 inch |
| Nominal impedance | 3.6Ω |
| Power rating | 10-40W |
| Sensitivity(1w\1m) | 85dB |
| Frequency range | 60Hz-4KHz |
| Voice coil diameter | Φ25 |
| Magnet dimension | 70*32*15 |
| Fs | 95.428 Hz |
| Re | 3.600 Ohm |
| Qms | 3.667 |
| Qes | 0.906 |
| Qts | 0.727 |
| Vas | 2.055 Ltr |
| Cms | 471.208u M/N |
| n.(%) | 0.191 % |
| Bl | 3.750 T |
| Sd | 5.542K mm |
